Blue Sea 8081 DC 5 Position Toggle Branch Circuit Breaker Panel - White Switches
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Blue Sea Systems
Buy With Confidence - Authorized Dealer
Sku :
BLU-8081Barcode :
632085080815
100% Brand new, authorized dealer
90 Day Returns on most items
Free delivery on most orders
8081 DC 5 Position Toggle Branch Circuit Breaker Panel - White Switches
Features:
- All positive, negative and grounding buses installed, fully pre-wired
- Panels with meters include toggle switch for mounting up to 3 battery banks
- All panels with analog meters are owner upgradable to 24 Volts with 8240 or 8243 (18-32V DC meters)
- All circuit label positions are backlit on standard panels - No kit required
- ON indicating LEDs installed in all circuit positions
Specifications:
- Positions: 5
- Nominal Voltage: 12v DC
- Maximum Amperage: 50A
- Height: 7.5
- Width: 5.25
- Depth: 2.5
- Weight: 2.25 lbs
Included:
- (5) 7210 A-Series White Toggle Circuit Breaker - Single Pole 15A
- (1) 8030 Basic DC Panel Label Set - 30 Labels
- (1) 8041 DC Micro Ammeter - 0 to 50A w/ Shunt (Meter)
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
| Brand | Blue Sea Systems |
| Voltage | 12V |
| Weight | 5.6 lb |
| Ac/Dc | Dc |
| Max Breaker Quantity | 5 |
| File Name | Link to the File |
|---|
